matches 1454 models Default Newest
DCA8-NM1500NM4.2-1792 Coaxial Cable

Coaxial Cable DCA8-NM1500NM4.2-1792

DC~18GHz, Semi flexible, 1500mm, N-J, N-J
In Stock View Details →
DCA8-NM120SM4.2-1820 Coaxial Cable

Coaxial Cable DCA8-NM120SM4.2-1820

DC~18GHz, Semi flexible, 120mm, N-J, SMA-J
In Stock View Details →
DCA8-NM100NM4.2-948 Coaxial Cable

Coaxial Cable DCA8-NM100NM4.2-948

DC~18GHz, Semi flexible, 100mm, N-J, N-J
In Stock View Details →
D8-QW400-1300 Waveguide adapter

Waveguide adapter D8-QW400-1300

Frequency32.9~50GHz, Waveguide quarter-wave
In Stock View Details →
D8-QW260-1220 Waveguide adapter

Waveguide adapter D8-QW260-1220

Frequency21700~33000MHz, Waveguide 1/4 wavelength line
In Stock View Details →
D8-AWC40NK-2347 Waveguide adapter

Waveguide adapter D8-AWC40NK-2347

Frequency3.22~4.9GHz, Power100W, Rect waveguider, N
In Stock View Details →
D8-AWC100NK-2695 Waveguide adapter

Waveguide adapter D8-AWC100NK-2695

Frequency8.2~12.5GHz, Power300W, Rect waveguider, FBP100, N
In Stock View Details →
D7-AWCWRD110C2.92K-2674 Waveguide adapter

Waveguide adapter D7-AWCWRD110C2.92K-2674

Frequency 11~26.5GHz, Power Capacity 25W (Design assurance), Ridged waveguide, 2.92-K
In Stock View Details →
D7-AWC70NK-1864 Waveguide adapter

Waveguide adapter D7-AWC70NK-1864

Frequency5.38~8.17GHz, Power Capacity100W, Rect waveguider, BJ70, N-K
In Stock View Details →
D25-BWC3202.92J-3504 Waveguide adapter

Waveguide adapter D25-BWC3202.92J-3504

Frequency26.3~40GHz, Power Capacity25W, Rect waveguider, BJ320 or WR28, 2.92
In Stock View Details →
D25-BWC26NK-260 Waveguide adapter

Waveguide adapter D25-BWC26NK-260

Frequency2.17~3.3GHz, Power Capacity500W, Rect waveguider, FDP26, N
In Stock View Details →
D25-AWCWRD580DNK-110 Waveguide adapter

Waveguide adapter D25-AWCWRD580DNK-110

Frequency5.8~16GHz, Average 300W. Peak 3000W, Ridged waveguide, WRD580, N
In Stock View Details →
2.92/SL-KJG Adapter

Adapter 2.92/SL-KJG

Frequency DC~40GHz, 2.92-K / SL-J, Stainless steel
In Stock View Details →
DWG25-BJ500S50-3790 Waveguide Connection

Waveguide Connection DWG25-BJ500S50-3790

Frequency 39.2~59.6GHz, Power Capacity 70W, Rect waveguider, BJ500 or WR19, BJ500 or WR19
In Stock View Details →
DWG25-BJ620S50-3795 Waveguide Connection

Waveguide Connection DWG25-BJ620S50-3795

Frequency 49.8~70GHz, Power Capacity 50W, Rect waveguider, BJ620 or WR15, BJ620 or WR15
In Stock View Details →
DWG25-BJ400S50-3794 Waveguide Connection

Waveguide Connection DWG25-BJ400S50-3794

Frequency 32.9~50.1GHz, Power Capacity 90W, Rect waveguider, BJ400 or WR22, BJ400 or WR22
In Stock View Details →

Can't find the right model?

Send us the frequency, power, interface and other specifications — our engineers will respond within one working day with a recommendation or a custom design.
