Frequency1~14GHz, Dynamic range-45~0dBm, SMA
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
small-volume
| Parameters | Min | Typical | Max | Units |
|---|---|---|---|---|
| Frequency | 1 | ~ | 14 | GHz |
| Dynamic range | -45 | ~ | 0 | dBm |
| Through loss | 1.2 | dB | ||
| Rising edge (input power≤0dBm) | 5 | ns | ||
| Falling edge (input power≤0dBm) | 50 | ns | ||
| Detection voltage range | 0~5 | V | ||
| Max input power | 18 | dBm |
| Connector | SMA-K |
| Connector material | Stainless steel |
| Surface | White |
| Working voltage | +12V |
| Working current | 100 |
| Work Temp. | -40~+70℃ Design assurance |
| 1 | Please do not wash the product in the cleaning solution.,Please do not wash the product in the cleaning solution. |
| 2 | If the temperature is higher than 125℃, consult with us before ordering. |
