F Low：824 - 837.5 MHz× Clear all
matches 132 models Default Newest
HF023 Filter

Filter HF023

Highpass F825~4000MHz, DC-250MHz≥30dB, 475MHz≥20dB, SMD, Industrial grade, 替代THP-825+
In Stock View Details →
ZBF15-L850-44-1080 Filter

Filter ZBF15-L850-44-1080

Passband828~872MHz, DC-780MHz≥40dB, 920-4000MHz≥40dB, SMD
In Stock View Details →
ZBF15-L850-44-1079 Filter

Filter ZBF15-L850-44-1079

Passband828~872MHz, DC-780MHz≥40dB, 920-4000MHz≥40dB, SMA
In Stock View Details →
ZBF2-L850-44-801 Filter

Filter ZBF2-L850-44-801

Passband828~872MHz, f0±75MHz≥35dBc, Pin
In Stock View Details →
K6-832-862-10S60100-002 Notch filter

Notch filter K6-832-862-10S60100-002

Stopband F832~862MHz, ≥60dB, PassbandDC~822MHz, 872~4000MHz, SMA
In Stock View Details →
K6-832-862-10S60100-001 Notch filter

Notch filter K6-832-862-10S60100-001

Stopband F832~862MHz, ≥60dB, PassbandDC~822MHz, 872~3000MHz, SMA
In Stock View Details →
K6-824-849-10S60100-002 Notch filter

Notch filter K6-824-849-10S60100-002

Stopband F824~849MHz, ≥50dB, PassbandDC~814MHz, 859~4000MHz, SMA
In Stock View Details →
K6-824-849-10N60100-001 Notch filter

Notch filter K6-824-849-10N60100-001

Stopband F824~849MHz, ≥50dB, PassbandDC~814MHz, 859~3000MHz, N
In Stock View Details →
K6-824-849-30S5050-005 Filter

Filter K6-824-849-30S5050-005

Stopband F824~849MHz, ≥50dB, PassbandDC~794MHz, 879~3500MHz, SMA
In Stock View Details →
ZCB6-C824-894-6194 Diplexer

Diplexer ZCB6-C824-894-6194

Passband frequency C1824~849MHz, Passband frequency C2869~894MHz, SMA
View Details →
ZCB4-C825-885-406 Diplexer

Diplexer ZCB4-C825-885-406

Passband F1825~840MHz, Passband F2870~885MHz, SMA
View Details →
ZCB4-C824-894-249 Diplexer

Diplexer ZCB4-C824-894-249

Passband L824~849MHz, Passband H869~894MHz, SMA
View Details →
ZBSF6-C837-857-4040 Filter

Filter ZBSF6-C837-857-4040

Stopband F837~857MHz, ≥55dB, PassbandDC~817MHz, 877~2500MHz, SMA
View Details →
ZBSF6-C837-857-1168 Filter

Filter ZBSF6-C837-857-1168

Stopband F837~857MHz, ≥40dB, PassbandDC~827MHz, 867~4000MHz, SMA
View Details →
ZBSF6-C836.5-836.7-6130 Filter

Filter ZBSF6-C836.5-836.7-6130

Stopband F836.5~836.7MHz, ≥45dB, PassbandDC~834.9MHz, 838.3~2350MHz, SMA
View Details →
ZBSF6-C836.5-836.7-5924 Filter

Filter ZBSF6-C836.5-836.7-5924

Stopband F836.5~836.7MHz, ≥40dB, PassbandDC~834.9MHz, 838.3~2500MHz, SMA
View Details →
ZBSF6-C836.5-836.7-4080 Filter

Filter ZBSF6-C836.5-836.7-4080

Stopband F836.5~836.7MHz, ≥40dB, PassbandDC~835.8MHz, 837.4~2350MHz, SMA
View Details →
ZBSF6-C836.5-836.7-2608 Filter

Filter ZBSF6-C836.5-836.7-2608

Stopband F836.5~836.7MHz, ≥50dB, PassbandDC~826.5MHz, 846.7~3000MHz, SMA
View Details →
ZBSF6-C836.4-836.8-3150 Filter

Filter ZBSF6-C836.4-836.8-3150

Stopband F836.4~836.8MHz, ≥40dB, PassbandDC~835.2MHz, 838~2500MHz, SMA
View Details →
ZBSF6-C836.3-836.9-4666 Filter

Filter ZBSF6-C836.3-836.9-4666

Stopband F836.3~836.9MHz, ≥40dB, PassbandDC~834.8MHz, 838.4~2350MHz, SMA
View Details →
ZBSF6-C836.3-836.5-4091 Filter

Filter ZBSF6-C836.3-836.5-4091

Stopband F836.3~836.5MHz, ≥50dB, PassbandDC~834.7MHz, 838.1~2350MHz, SMA
View Details →
ZBSF6-C836.2-836.6-4445 Filter

Filter ZBSF6-C836.2-836.6-4445

Stopband F836.2~836.6MHz, ≥35dB, PassbandDC~835MHz, 837.8~2300MHz, SMA
View Details →
ZBSF6-C834.1-839.1-4023 Filter

Filter ZBSF6-C834.1-839.1-4023

Stopband F834.1~839.1MHz, ≥55dB, PassbandDC~824.1MHz, 849.1~2500MHz, SMA
View Details →
ZBSF6-C832.5-837.5-3887 Filter

Filter ZBSF6-C832.5-837.5-3887

Stopband F832.5~837.5MHz, ≥40dB, PassbandDC~827.5MHz, 842.5~3000MHz, SMA
View Details →

Can't find the right model?

Send us the frequency, power, interface and other specifications — our engineers will respond within one working day with a recommendation or a custom design.
