F High：1626 - 1629 MHz× Clear all
matches 30 models Default Newest
WLMF1618B022AK Filter

Filter WLMF1618B022AK

Passband1618MHz, DC-1.55GHz≥3840dB, 1.55-1.575GHz≥3035dB, 1.755-2.7GHz≥3840dB, Microstrip pad, FBAR
In Stock View Details →
ZBF5-L1575.5-103-2322 Filter

Filter ZBF5-L1575.5-103-2322

Passband1524~1627MHz, DC-1424MHz≥40dB, 1727-7000MHz≥40dB, SMA
In Stock View Details →
ZBF5-L1575.5-103-2345 Filter

Filter ZBF5-L1575.5-103-2345

Passband1524~1627MHz, DC-1344MHz≥40dB, 1790-4000MHz≥40dB, SMD
In Stock View Details →
ZBF13-C1621.25-10.5-2296 Filter

Filter ZBF13-C1621.25-10.5-2296

Passband1616~1626.5MHz, 1566MHz≥40dBc, 1676MHz≥40dBc, SMA
In Stock View Details →
ZBF2-C1618.5-17-3366 Filter

Filter ZBF2-C1618.5-17-3366

Passband1610~1626.5MHz, 1258-1279MHz≥60dBc, 1570-1580MHz≥40dBc, SMA, Industrial grade
In Stock View Details →
ZBSF6-C1620.524-1628.524-3549 Filter

Filter ZBSF6-C1620.524-1628.524-3549

Stopband F1620.524~1628.524MHz, ≥70dB, PassbandDC~1575MHz, 1673~4000MHz, SMA
View Details →
ZBSF6-C1610-1626.5-5432 Filter

Filter ZBSF6-C1610-1626.5-5432

Stopband F1610~1626.5MHz, ≥50dB, PassbandDC~1605MHz, 1631.5~4000MHz, SMA
View Details →
ZBSF6-C1610-1626.5-5402 Filter

Filter ZBSF6-C1610-1626.5-5402

Stopband F1610~1626.5MHz, ≥50dB, PassbandDC~1598MHz, 1638.5~6000MHz, SMA
View Details →
ZBSF15-L1429-1626-1707 Filter

Filter ZBSF15-L1429-1626-1707

Stopband F1429~1626MHz, ≥45dBc, Passband350~1310MHz, 1770~2000MHz, SMD
View Details →
ZBF9-D1624.52-3.28-2908 Filter

Filter ZBF9-D1624.52-3.28-2908

Passband1622.88~1626.16MHz, fo±51.5MHz≥35dBc, SMD
View Details →
ZBF9-D1622.42-8.16-2914 Filter

Filter ZBF9-D1622.42-8.16-2914

Passband1618.34~1626.5MHz, fo±54MHz≥35dBc, SMD
View Details →
ZBF9-D1621.5-131-2389 Filter

Filter ZBF9-D1621.5-131-2389

Passband1616~1626.5MHz, DC-1596MHz≥30dB, 1647-2500MHz≥30dB, SMD
View Details →
ZBF9-D1621.5-11-2388 Filter

Filter ZBF9-D1621.5-11-2388

Passband1616~1626.5MHz, DC-1596MHz≥30dB, 1647-2500MHz≥30dB, SMD
View Details →
ZBF6-C1618.25-16.5-6180 Filter

Filter ZBF6-C1618.25-16.5-6180

Passband1610~1626.5MHz, DC-1590MHz≥60dB, 1646.5-8000MHz≥60dB, SMA
View Details →
ZBF5-C1618.5-17-2807 Filter

Filter ZBF5-C1618.5-17-2807

Passband1610~1627MHz, DC-1278MHz≥75dB, 1560-1580MHz≥55dB, MCX
View Details →
ZBF5-C1618.5-17-1783 Filter

Filter ZBF5-C1618.5-17-1783

Passband1610~1627MHz, DC-1278MHz≥75dB, 1560-1580MHz≥55dB,
View Details →
ZBF4-C1621.25-10.5-1418 Filter

Filter ZBF4-C1621.25-10.5-1418

Passband1616~1626.5MHz, 1566MHz≥40dB, 1666MHz≥40dB, SMA
View Details →
ZBF4-C1621.25-10.5-1001 Filter

Filter ZBF4-C1621.25-10.5-1001

Passband1616~1626.5MHz, 1580MHz≥30dB, 1660MHz≥30dB, SMA
View Details →
ZBF4-C1618.25-16.5-1000 Filter

Filter ZBF4-C1618.25-16.5-1000

Passband1610~1626.5MHz, 1570MHz≥40dB, 1665MHz≥40dB, SMA
View Details →
ZBF4-C1572.25-108.5-993 Filter

Filter ZBF4-C1572.25-108.5-993

Passband1518~1626.5MHz, 1490MHz≥30dB, 1655MHz≥30dB, SMA
View Details →
ZBF4-C1572.25-108.5-854 Filter

Filter ZBF4-C1572.25-108.5-854

Passband1518~1626.5MHz, DC-1488MHz≥30dB, 1656.5-3000MHz≥30dB, SMA
View Details →
ZBF3-L1618.5-17-4043 Filter

Filter ZBF3-L1618.5-17-4043

Passband1610~1627MHz, DC-1268MHz≥50dB, 2491-3500MHz≥60dB, SMA
View Details →
ZBF3-L1618.5-17-2647 Filter

Filter ZBF3-L1618.5-17-2647

Passband1610.18~1626.5MHz, DC-1268MHz≥50dBc, 2491MHz≥60dBc, Pin
View Details →
ZBF3-C1621.25-10.5-4076 Filter

Filter ZBF3-C1621.25-10.5-4076

Passband1616~1626.5MHz, 1580MHz≥40dB, 1660MHz≥40dB, Pin
View Details →
