12V DC power supply, supporting 110-220V power supply and DC power supply.
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
| Application | Used for indoor and outdoor RF testing platforms, it can power active devices such as RF amplifiers. Adapt to COM-MW low noise amplifier and power power amplifier. |
|---|---|
| Characteristic | 12V DC power supply, supporting 110-220V power supply and DC power supply. |
| 1 | RF Port | SMA-K or N-K with frequencies below 18GHz; Frequency 18-40GHz with 2.92-K; Above 40GHz with 2.4-K or 1.85-K. |
|---|---|---|
| 2 | Power supply method 1 | 110-220V power input, standard AC interface, 12-15V/5W output. |
| 3 | Power supply method 2 | DC power supply, powered by a 220V power adapter with interface DC5.5mm (outer diameter) * 2.5mm (inner diameter). |
| 5 | Work Temp. | -20~+60℃ Design assurance |
| 6 | Surface color | Anodizing treatment (blue) |
| 7 | Shell Material | Shell aluminum material |
| 8 | DC output | The DC power supply voltage is determined by the input voltage of the internal module. |
| 9 | Instructions for using the power switch | 220V and DC power supply cannot be used simultaneously. |
| 1 | Standard configuration | 220V AC power cord |
|---|---|---|
| 2 | Optional | Equipped with a power adapter |
| 1 | Please do not wash the product in the cleaning solution.,Please do not wash the product in the cleaning solution. |
|---|---|
| 2 | If the temperature is higher than 125℃, consult with us before ordering. |
