1~18GHz, 1W, 2way, 0°, SMA
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
| Parameters | Min | Typical | Max | Units |
|---|---|---|---|---|
| Frequency | 1 | ~ | 18 | GHz |
| IL | 9 | dB | ||
| Isolation | 12 | dB | ||
| Input VSWR | 2 | |||
| Amplitude balance | ±1 | dB | ||
| Phase balance | ±2 | ° |
| Power Capacity | 1W Design assurance |
| X-Way | 2-way |
| Phase | 0° |
| Impedance | 50Ω |
| Connector | SMA |
| Surface | Conductive oxidation |
| Operation Temp. | -40~+65℃ Design assurance |
| Other | 1、输入限幅设计，限幅输出功率：16dBm（设计保证）2、输入输出隔直 |
| Common port | 0 |
| Dispatch Port | 1,2 |
