| Parameters | Min | Typical | Max | Units |
|---|---|---|---|---|
| Frequency | 27000 | ~ | 33000 | MHz |
| IL | 15.8 | dB | ||
| Isolation | 13 | dB | ||
| Input VSWR | 1.6 | |||
| Output VSWR | 1.5 | |||
| Amplitude balance | 0.6 | dB | ||
| Phase balance | ±6 | ° |
| Power | 2W |
| way | 24-way |
| Phase | 0° |
| Impedance | 50Ω |
| Connector | 2.92-K |
| Connector material | Stainless steel |
| Surface | Black baking paint |
| Work Temp. | -40~+70℃ Design assurance |
| 1 | Please do not wash the product in the cleaning solution.,Please do not wash the product in the cleaning solution. |
| 2 | If the temperature is higher than 125℃, consult with us before ordering. |
