| Parameters | Min | Typical | Max | Units |
|---|---|---|---|---|
| Frequency | 8 | ~ | 12 | GHz |
| IL | 1.2 | dB | ||
| Isolation | 5 | dB | ||
| Input VSWR | 1.4 | |||
| Output VSWR | Not have | |||
| Amplitude balance | 0.4 | dB | ||
| Phase balance | 10 | ° |
| Power Capacity | 400W |
| X-Way | 12-way |
| Phase | 0° |
| Impedance | 50Ω |
| Connector | N-K |
| Operation Temp. | -30~+70℃ Design assurance |
| 1 | Clean the surface of the product, do not soak the product in cleaning solution for cleaning. |
| 2 | If the temperature is higher than 125℃, consult with us before ordering. |
