40~50GHz, 150W, 2way, 0°, Waveguide
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
| Parameters | Min | Typical | Max | Units |
|---|---|---|---|---|
| Frequency | 40 | ~ | 50 | GHz |
| IL | 0.5 | dB | ||
| Theoretical loss | 3 | dB | ||
| 1,2 Port ISO | 15 | dB | ||
| 0,3 Port ISO | 30 | dB | ||
| 0，3端口驻波比 | 1.5 | |||
| 1，2端口驻波比 | 1.3 | |||
| Amplitude balance | 0.3 | dB | ||
| Phase balance | 5 | ° |
| Power Capacity | 150W Design assurance |
| Peak power | 1000W设计保证，占空比10%，脉冲宽度60uS |
| X-Way | 2-way |
| Phase | 0° |
| Connector | Waveguide |
| Waveguide port | BJ400 or WR22 |
| Waveguide flange | FUGP400 |
| Surface | Conductive oxidation |
| Product shell material | Aluminium |
| Operation Temp. | -40~+70℃ Design assurance |
| Quality Grade | Industrial grade |
| Common port | 0 |
| Dispatch Port | 1，2 |
| Isolated Port | 3 |
| 1 | Clean the surface of the product, do not soak the product in cleaning solution for cleaning. |
| 2 | If the temperature is higher than 125℃, consult with us before ordering. |
