200~300 (low pass)MHz, 300~500 (low pass)MHz, 500~800 (low pass)MHz, 800~1300 (low pass)MHz, 1300~2200 (low pass)MHz, SMA
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
| Parameters | Frequency | / | Min | Typical | Max | Units |
|---|---|---|---|---|---|---|
| Passband F1 | / | / | 200 | ~ | 300 (low pass) | MHz |
| Passband F2 | / | / | 300 | ~ | 500 (low pass) | MHz |
| Passband F3 | / | / | 500 | ~ | 800 (low pass) | MHz |
| Passband F4 | / | / | 800 | ~ | 1300 (low pass) | MHz |
| Passband F5 | / | / | 1300 | ~ | 2200 (low pass) | MHz |
| Passband VSWR | ≤ | 1.5 | ||||
| Passband IL | ≤ | 2.0 | dB | |||
| Rejection | 2nd harmonic | 60 | dB |
| Connector | SMA-K |
| Connector material | Housing 304 stainless steel |
| Impedance | 50Ω |
| Surface | White |
| Consistence | / |
| Operation Temp. | -40~+70℃ Design assurance |
| Storage Temp. | -55~+85℃ Design assurance |
| 1 | Clean the surface of the product, do not soak the product in cleaning solution for cleaning. |
