PassbandDC~1800MHz, 2400-8500MHz≥40dB, SMA
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
High Q, low loss and high power.
| Parameters | Frequency | / | Min | Typical | Max | Units |
|---|---|---|---|---|---|---|
| Passband | DC | ~ | 1800 | MHz | ||
| Passband IL | 1.0 | dB | ||||
| Rejection | 2400-8500 | MHz≥ | 40 | dB | ||
| Passband VSWR | 1.3 |
| Connector | SMA-K |
| Connector material | 外壳316不锈钢（表面钝化） |
| Impedance | 50Ω |
| Surface | Conductive oxidation |
| Power | 2W Design assurance |
| Product shell material | 铝5A06 |
| Relative humidity | 93%RH @35℃ |
| Work Temp. | -10~+45℃ |
| Storage Temp. | -41~+69℃ |
| Quality Grade | Industrial grade |
| -3dB截止频率 | 2100MHz<-3dB |
| 1 | Please do not wash the product in the cleaning solution.,Please do not wash the product in the cleaning solution. |
| 2 | If the temperature is higher than 125℃, consult with us before ordering. |
