Low loss.
| Parameters | Frequency | / | Min | Typical | Max | Units |
|---|---|---|---|---|---|---|
| Passband | DC | ~ | 1800 | MHz | ||
| Passband IL | 1.0 | dB | ||||
| Passband VSWR | 1.4 | |||||
| Rejection | 2800-8500 | MHz≥ | 40 | dB |
| Connector | SMA-K |
| Impedance | 50Ω |
| Surface | silver-plate |
| Power Capacity | 2W |
| Operation Temp. | -45~+80℃ Design assurance |
| Storage Temp. | -55~+85℃ Design assurance |
| Quality Grade | Industrial grade |
| Other | -3dB截止频率: 1920MHz 器件:全国产普军级（样 品阶段产品元器件使用普 通国产器件；批量定型后 使用全国产普军级器件。 ） |
| 1 | Clean the surface of the product, do not soak the product in cleaning solution for cleaning. |
| 2 | If the temperature is higher than 125℃, consult with us before ordering. |
| 3 | Installation surface is flat. |
