It has the characteristics of wide bandwidth, low sidelobes, and high efficiency.
| Parameters | Min | Typical | Max | Units |
| Frequency | 5.38 | ~ | 8.17 | GHz |
| Gain | 10 | dBi | ||
| VSWR | 1.35 | |||
| power | 50 | W |
| Polarization | Linear Pol. |
| Connector | SMA-K |
| Outline size | 80*80*167mm |
| Estimated weight | 0.28Kg |
| surface treatment | Grey |
| Operation Temp. | -25~+45℃ Design assurance |
| Storage Temp. | -45~+75℃ Design assurance |
