Passband300~8000MHz, DC-200MHz≥60dB, 250MHz≥37dB, SMA
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
| Parameters | Frequency | / | Min | Typical | Max | Units |
|---|---|---|---|---|---|---|
| Passband | / | / | 300 | ~ | 8000 | MHz |
| Passband IL | 300 | MHz | 8.0 | dB | ||
| Passband IL | 320 | MHz | 2.0 | dB | ||
| Passband IL | 350-8000 | MHz | 1.0 | dB | ||
| Ripple | 350-8000 | MHz | 1.0 | dB | ||
| Rejection | DC-200 | MHz≥ | 60 | dB | ||
| Rejection | 250 | MHz≥ | 37 | dB | ||
| Rejection | 270 | MHz≥ | 25 | dB | ||
| Passband VSWR | 350 | 8000 | 1.6 |
| Connector | SMA-F |
| Connector material | Stainless steel |
| Impedance | 50Ω |
| Surface | Black baking paint |
| Power Capacity | 1W Design assurance |
| Product shell material | Aluminium |
| Operation Temp. | -40~+70℃ |
| Storage Temp. | -55~+85℃ Design assurance |
| Other | 端口标识:激光刻字，温度下损耗≤1.3dB（350-8000MHz）振动（设计保证）Vertical-2.24 grams Transverse-1.45grams Longitudinal- 1.9grams TestTime-40minutesperaxis冲击（设计保证）20g,11msec |
| 1 | Clean the surface of the product, do not soak the product in cleaning solution for cleaning. |
| 2 | If the temperature is higher than 125℃, consult with us before ordering. |
