88~112MHz, 10W, 90°Hybrid, SMD
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
| Parameters | Min | Typical | Max | Units |
|---|---|---|---|---|
| Frequency | 88 | ~ | 112 | MHz |
| IL | 0.3 | dB | ||
| Isolation | 23 | dB | ||
| VSWR | 1.2 | |||
| Amplitude balance | 0.3 | dB | ||
| Phase balance | 2 | ° |
| Power | 10W |
| Phase | 90° Hybrid |
| Impedance | 50Ω |
| Connector | SMD |
| Work Temp. | -40~+130℃设计保证 |
| Port 1 | 输入/隔离(外接50Ω负载) |
| Port 2 | 隔离(外接50Ω负载)/输入 |
| 端口3 | 输出2（0°）/输出1（+90°） |
| 端口4 | 输出1（+90°）/输出2（0°） |
| GND | Other ports |
| 1 | Please do not wash the product in the cleaning solution.,Please do not wash the product in the cleaning solution. |
| 2 | If the temperature is higher than 125℃, consult with us before ordering. |
