Small size, high power.
| Parameters | Min | Typical | Max | Units |
|---|---|---|---|---|
| Frequency | 70 | ~ | 90 | MHz |
| IL | 0.2 | dB | ||
| Coupling | 58 | 60 | 62 | dB |
| Directivity | 20 | dB | ||
| Main line VSWR | 1.1 | |||
| Coupled line VSWR | 1.3 |
| Input connector | N -K |
| Connector | SMA-K |
| Impedance | 50Ω |
| Power Capacity | 2000W |
| Operation Temp. | -40~+85℃ Design assurance |
| 1 | Clean the surface of the product, do not soak the product in cleaning solution for cleaning. |
| 2 | If the temperature is higher than 125℃, consult with us before ordering. |
