| Parameters | Min | Typical | Max | Units |
|---|---|---|---|---|
| Frequency | 430 | ~ | 6000 | MHz |
| IL | 2 | dB | ||
| Coupling | 5.8 | 7 | 8.2 | dB |
| Directivity | 15 | dB | ||
| Main line VSWR | 1.3 | |||
| Coupled line VSWR | 1.5 |
| Connector | N -K |
| Impedance | 50Ω |
| Power Capacity | 50W |
| Operation Temp. | -30~+70℃ Design assurance |
| Other | Including distribution loss of 0.97dB |
| Input port | IN |
| Output port | OUT |
| Coupling port | C |
| 1 | Clean the surface of the product, do not soak the product in cleaning solution for cleaning. |
