发射频率6300~6600MHz, 接收频率6950~7250MHz, SMA
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
| Parameters | Frequency | / | Min | Typical | Max | Units |
|---|---|---|---|---|---|---|
| 发射频率 | / | / | 6300 | ~ | 6600 | MHz |
| 接收频率 | / | / | 6950 | ~ | 7250 | MHz |
| Passband IL | / | / | 0.8 | dB | ||
| Passband VSWR | / | / | 1.5 | |||
| 发射抑制度 | 6950-7250 | MHz≥ | 90 | dB | ||
| 接收抑制度 | 6300-6600 | MHz≥ | 100 | dB |
| Connector | SMA-F Detachable Pin 0.5mm |
| Connector material | Stainless steel |
| Impedance | 50Ω |
| Surface | silver-plate |
| Power Capacity | 80W发射通道 |
| Product shell material | Aluminium |
| Operation Temp. | -40~+70℃ |
| Storage Temp. | -55~+85℃ Design assurance |
| 1 | Common port | --- |
|---|---|---|
| 2 | Passband 1 | --- |
| 3 | Passband 2 | --- |
| 4 | GND Port | --- |
| 1 | Clean the surface of the product, do not soak the product in cleaning solution for cleaning. |
| 1 | If the temperature is higher than 125℃, consult with us before ordering. |
