Port1中心频率 GHz, Port2中心频率 GHz, 1dB BW 300MHz, 2.92
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
| Parameters | Frequency | / | Min | Typical | Max | Units |
| Center frequency of Port1 Center frequency of Port1 Center frequency of Port1 Center frequency of Port1 | 10.65 | / | GHz | |||
| Center frequency of Port2 | 21.54 | / | GHz | |||
| 1dB BW | / | / | 300 | MHz | ||
| Passband IL | / | / | 1.0 | dB | ||
| Passband ripple | / | / | 1.0 | dB | ||
| Passband VSWR | / | / | 1.5 | |||
| Rejection of Port1 | 21.54 | GHz≥ | 50 | dBc | ||
| Rejection of Port1 | 2nd harmonic | 40 | dBc | |||
| Rejection of Port2 | 10.65 | GHz≥ | 50 | dBc | ||
| Rejection of Port2 | 2nd harmonic | 40 | dBc |
| Connector | 2.92-F |
| Connector material | Stainless steel |
| Product shell material | Copper |
| Operation Temp. | -40~+70℃ Design assurance |
| Storage Temp. | -55~+85℃ Design assurance |
| 1 | Clean the surface of the product, do not soak the product in cleaning solution for cleaning. |
| 1 | If the temperature is higher than 125℃, consult with us before ordering. |
