Passband RF1600~700MHz, Passband RF21200~2100MHz, 1200~2100MHz≥75dBc, 600~700MHz≥75dBc, SMA
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
| Parameters | Frequency | / | Min | Typical | Max | Units |
|---|---|---|---|---|---|---|
| Passband RF1 | / | / | 600 | ~ | 700 | MHz |
| Passband RF2 | / | / | 1200 | ~ | 2100 | MHz |
| Passband IL | / | / | 1 | dB | ||
| Passband ripple | / | / | 0.6 | |||
| Passband VSWR RF1 | / | / | 1.5 | |||
| Passband VSWR RF2 | / | / | 1.8 | |||
| Band 1 Rejection | 1200~2100 | MHz≥ | 75 | dBc | ||
| band 2 Rejection | 600~700 | MHz≥ | 75 | dBc |
| Connector | SMA-K |
| Impedance | 50Ω |
| Surface | silver-plate |
| Power Capacity | 50W Design assurance |
| Operation Temp. | -40~+70℃ Design assurance |
| Storage Temp. | -55~+85℃ Design assurance |
| 1 | Clean the surface of the product, do not soak the product in cleaning solution for cleaning. |
