Pass band TX15.2~6.2GHz, Pass band TX28~12GHz, 8~12GHz≥40dB, 5.2~6.2GHz≥40dB,
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
| Parameters | Frequency | / | Min | Typical | Max | Units |
|---|---|---|---|---|---|---|
| Pass band TX1 | / | / | 5.2 | ~ | 6.2 | GHz |
| Pass band TX2 | / | / | 8 | ~ | 12 | GHz |
| band 1 IL | / | / | 0.5 | dB | ||
| band 2 IL | / | / | 0.5 | dB | ||
| Passband ripple | / | / | 0.3 | dB | ||
| Passband VSWR | / | / | 1.8 | |||
| Band 1 Rejection TX1 | 8~12 | GHz≥ | 40 | dB | ||
| band 2 Rejection TX2 | 5.2~6.2 | GHz≥ | 40 | dB |
| Connector | 0.5mm |
| Impedance | 50Ω |
| Surface | silver-plate |
| Power Capacity | 30W Design assurance |
| 相对一致性 | ±2.5° |
| Operation Temp. | -30~+70℃ Design assurance |
| Storage Temp. | -40~+80℃ Design assurance |
| 1 | Clean the surface of the product, do not soak the product in cleaning solution for cleaning. |
