Stopband F2400~2500MHz, ≥50dB, PassbandDC~2170MHz, 3000~18000MHz, SMA, Replace BRM50702
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
Ultra wide passband, small volume. Applied in the field of WIFI testing.
| Parameters | / | Min | Typical | Max | Units |
|---|---|---|---|---|---|
| Stopband F | 2400 | ~ | 2500 | MHz | |
| Stopband Rej. | ≥ | 50 | dB | ||
| Passband | DC | ~ | 2170 | MHz | |
| Passband | 3000 | ~ | 18000 | MHz | |
| Passband IL | 2 | dB | |||
| Passband VSWR | 2 |
| Connector | SMA-K |
| Connector material | Stainless steel |
| Impedance | 50Ω |
| Surface | Black |
| Power | 2W Design assurance |
| Work Temp. | -30~+60℃ Design assurance |
| Quality Grade | Industrial grade |
| Other | Replace BRM50702 |
| 1 | Please do not wash the product in the cleaning solution.,Please do not wash the product in the cleaning solution. |
| 2 | If the temperature is higher than 125℃, consult with us before ordering. |
