Stopband F188~108MHz, Stopband F2825~960MHz, ≥30dB, PassbandDC~70MHz, 128~750MHz, 1010~1350MHz, N
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
| Parameters | / | Min | Typical | Max | Units |
|---|---|---|---|---|---|
| Stopband F1 | 88 | ~ | 108 | MHz | |
| Stopband F2 | 825 | ~ | 960 | MHz | |
| Stopband Rej. | ≥ | 30 | dB | ||
| Passband | DC | ~ | 70 | MHz | |
| Passband | 128 | ~ | 750 | MHz | |
| Passband | 1010 | ~ | 1350 | MHz | |
| Passband IL | 3.0 | dB | |||
| Passband VSWR | 1.5 |
| Connector | N -MF |
| Connector material | Stainless steel |
| Impedance | 50Ω |
| Surface | Breen |
| Power Capacity | 1W Design assurance |
| Operation Temp. | -40~+55℃ Design assurance |
| Storage Temp. | -55~+70℃ Design assurance |
