Passband1292~1398MHz, F0±100MHz≥dB, F0±150MHz≥dB, Pin
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
| Parameters | Frequency | / | Min | Typical | Max | Units |
|---|---|---|---|---|---|---|
| Passband | / | / | 1292 | ~ | 1398 | MHz |
| Passband IL | / | / | 0.7 | dB | ||
| Ripple | / | / | dB | |||
| Rejection | F0±100 | MHz≥ | 50 | dB | ||
| Rejection | F0±150 | MHz≥ | 80 | dB | ||
| Rejection | F0±250 | MHz≥ | 100 | dB | ||
| Passband VSWR | / | / | 1.3 | |||
| / | / | dB |
| Connector | 微带圆针可拆0.5mm针绝缘子最小不低于Φ4mm |
| Impedance | 50Ω |
| Surface | White |
| Power Capacity | 500W @ pulse width 80us, duty cycle 15% design guarantee |
| Phase balance | ±5° |
| Operation Temp. | -40~+70℃ |
| 1 | Clean the surface of the product, do not soak the product in cleaning solution for cleaning. |
| 2 | If the temperature is higher than 125℃, consult with us before ordering. |
| 3 | / |
