Passband69.6~70.4MHz, -40dB BW4.5MHz, Rejection40dB, SMA
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
| Parameters | Frequency | Min | Typical | Max | Units | |
|---|---|---|---|---|---|---|
| Passband | 69.6 | ~ | 70.4 | MHz | ||
| Center loss | 5 | dB | ||||
| 1dB BW | 0.7 | 0.8 | MHz | |||
| -3dB BW | 1.4 | 1.5 | MHz | |||
| -40dB BW | 4.5 | 4.6 | MHz | |||
| Rejection | 40 | dB |
| Connector | SMA-K |
| Connector material | Stainless steel |
| Surface | silver-plate |
| Power Capacity | 0.1W Design assurance |
| Product shell material | Aluminium |
| absolute delay | ≤700ns |
| Delay ripple | ≤100ns |
| Operation Temp. | -40~+70℃ Design assurance |
| 1 | Clean the surface of the product, do not soak the product in cleaning solution for cleaning. |
