Pass band RF1510~678MHz, Pass band RF2510~678MHz, 435MHz≥20dBc, 0.728-1GHz≥20dBc, SMA
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
| Parameters | Frequency | / | Min | Typical | Max | Units |
|---|---|---|---|---|---|---|
| Pass band RF1 | / | / | 510 | ~ | 678 | MHz |
| Pass band RF2 | / | / | 510 | ~ | 678 | MHz |
| Passband IL | / | / | 1.5 | dB | ||
| Ripple | / | / | 1.0 | dB | ||
| Rejection | 435 | MHz≥ | 20 | dBc | ||
| Rejection | 0.728-1 | GHz≥ | 20 | dBc | ||
| Rejection | 1-3 | GHz≥ | 40 | dBc | ||
| Rejection | DC-400 | MHz≥ | 40 | dBc | ||
| Passband VSWR | / | / | 1.5 |
| Connector | SMA-F or K |
| Connector material | Stainless steel |
| Impedance | 50Ω |
| Surface | White Conductive Oxidation |
| Power Capacity | 20W Design assurance |
| Product shell material | Aluminium |
| Operation Temp. | -40~+70℃ Design assurance |
| Storage Temp. | -55~+85℃ Design assurance |
| 工作环境 | ＜海拔5000米 |
| Weight | ＜90g |
| 1 | Clean the surface of the product, do not soak the product in cleaning solution for cleaning. |
| 2 | If the temperature is higher than 125℃, consult with us before ordering. |
