Passband3000~5000MHz, DC~1500MHz≥45dBc, 6500~15000MHz≥45dBc, SMP
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
| Parameters | Frequency | / | Min | Typical | Max | Units |
|---|---|---|---|---|---|---|
| Passband | / | / | 3000 | ~ | 5000 | MHz |
| Passband IL | / | / | 1 | dB | ||
| Ripple | / | / | 0.8 | dB | ||
| Rejection | DC~1500 | MHz≥ | 45 | dBc | ||
| Rejection | 6500~15000 | MHz≥ | 45 | dBc | ||
| Passband VSWR | / | / | 1.5 | |||
| Return loss | / | / | dB |
| Connector | SMP-J |
| Impedance | 50Ω |
| Surface | Color conductive oxidation |
| Power Capacity | 2W Design assurance |
| Delay ripple | ≤1ns |
| Operation Temp. | -55~+85℃ Design assurance |
| Storage Temp. | -55~+85℃ Design assurance |
| Thermal Shock | 温度范围:－55～＋85℃； 温控误差:高温:±2℃，低温:±2℃； 温度变化速率:不小于5℃/min； 高低温保持时间:温度平衡时间为2h； 循环次数:2次； |
| vibration test | 随机振动要求:设计保证 频率范围:20-2000Hz 功率谱密度（PSL）:20～80Hz3dB/oct 80～350Hz0.04g2/Hz 350～2000Hz-3dB/oct 均方根加速度值（Grms）:6.06g 时间要求:3个轴向，X/Y/Z每轴各5分钟 |
| other | Weighing approximately 40g |
