Passband3300~3600MHz, DC~3250MHz≥60dBc, 3650~8000MHz≥60dBc, GHz≥dB, GHz≥dB, N
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
| Parameters | Frequency | / | Min | Typical | Max | Units |
|---|---|---|---|---|---|---|
| Passband | / | / | 3300 | ~ | 3600 | MHz |
| Passband IL | / | / | 0.6 | dB | ||
| Ripple | / | / | 0.6 | dB | ||
| Rejection | DC~3250 | MHz≥ | 60 | dBc | ||
| Rejection | 3650~8000 | MHz≥ | 60 | dBc | ||
| Passband VSWR | / | / | 1.5 | |||
| Return loss | / | / | dB |
| Connector | N -K |
| Connector material | Stainless steel |
| Impedance | 50Ω |
| Surface | Color conductive oxidation |
| Power Capacity | 20W设计保证满足海拔8000 米，功率40W 正常工作 |
| Operation Temp. | -40~+85℃ Design assurance |
| Storage Temp. | -55~+85℃ Design assurance |
| Thermal Shock | 温度范围:－50～＋85℃； 温控误差:高温:±2℃，低温:±2℃； 温度变化速率:不小于5℃/min； 高低温保持时间:温度平衡时间为2h； 循环次数:2 次； |
| Shock | 执行标准:符合GJB 367A-2001 中A04 冲击试验5.1 方法1 三个相互垂直轴的正负轴向各进行3 次，共计18 次冲击试验 |
| vibration test | 随机振动要求:频率范围:20-2000Hz 功率谱密度（PSL）: 20～80Hz 3dB/oct 80～350Hz 0.04g2/Hz 350～2000Hz -3dB/oct 均方根加速度值（Grms）: 6.06g 时间要求:3 个轴向，X/Y/Z 每轴各5 分钟 |
| （高度）低气压 | 海拔1万米 |
| Other | 外壳材料铝合金， 表面彩色导电氧化 |
| 1 | Clean the surface of the product, do not soak the product in cleaning solution for cleaning. |
