Passband5000~5850MHz, DC-4800MHz≥65dBc, 4800-4900MHz≥35dBc, Pin
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
| Parameters | Frequency | / | Min | Typical | Max | Units |
|---|---|---|---|---|---|---|
| Passband | / | / | 5000 | ~ | 5850 | MHz |
| Passband IL | / | / | 2.5 | dB | ||
| Ripple | / | / | 0.5 | dB | ||
| Rejection | DC-4800 | MHz≥ | 65 | dBc | ||
| Rejection | 4800-4900 | MHz≥ | 35 | dBc | ||
| Rejection | 6500-8000 | MHz≥ | 75 | dBc | ||
| Rejection | 8-15 | GHz≥ | 20 | dBc | ||
| Passband VSWR | / | / | 1.5 | |||
| Reverse isolation | ＞20dB |
| Connector | 微带圆针0.5mm针腔体端口微带针，隔离器为微带片 |
| Impedance | 50Ω |
| Surface | silver-plate |
| Power Capacity | 5W Design assurance |
| Bandwidth | -1dB≥900MHz |
| Operation Temp. | -45~+70℃ Design assurance |
| Storage Temp. | -55~+85℃ Design assurance |
| Other | 隔离器输入腔体输出 |
| 1 | Clean the surface of the product, do not soak the product in cleaning solution for cleaning. |
