Passband734~844MHz, DC-639MHz≥50dB, 939-2500MHz≥50dB, Pin 0.5mm
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
| Parameters | Frequency | / | Min | Typical | Max | Units |
|---|---|---|---|---|---|---|
| Passband | / | / | 734 | ~ | 844 | MHz |
| Passband IL | / | / | 2.2 | dB | ||
| Ripple | / | / | 1.0 | dB | ||
| Rejection | DC-639 | MHz≥ | 50 | dB | ||
| Rejection | 939-2500 | MHz≥ | 50 | dB | ||
| Passband VSWR | / | / | 1.8 |
| Connector | Pin 0.5mm |
| Impedance | 50Ω |
| Surface | Silver plating |
| Power | 1W |
| Bandwidth | -1dB≥110MHz |
| Work Temp. | -55~+85℃ Design assurance |
| Storage Temp. | --60~+90℃设计保证 |
| 距形系数 | <.2.8@BW-45dB/BW-3dB |
| 1 | Please do not wash the product in the cleaning solution.,Please do not wash the product in the cleaning solution. |
