Passband3850~4350MHz, DC-3.5GHz≥60dB, 3.6-3.82GHz≥5dB, Pin
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
| Parameters | Frequency | / | Min | Typical | Max | Units |
|---|---|---|---|---|---|---|
| Passband | / | / | 3850 | ~ | 4350 | MHz |
| Passband IL | / | / | 2.0 | dB | ||
| Ripple | / | / | 0.6 | dB | ||
| Rejection | DC-3.5 | GHz≥ | 60 | dB | ||
| Rejection | 3.6-3.82 | GHz≥ | 5 | dB | ||
| Rejection | 4.8-11 | GHz≥ | 60 | dB | ||
| Passband VSWR | / | / | 1.50 |
| Connector | Pin 0.5mm |
| Impedance | 50Ω |
| Surface | silver-plate |
| Power Capacity | 5W Design assurance |
| Shock | 冲击脉冲波形为半正弦波，峰值加速度为20g,脉冲宽度为11ms,每个轴向3次。设计保证 |
| vibration test | 正弦扫频5Hz-200Hz,其中5Hz-5.5Hz振动位移为25.4mm,5Hz-200Hz振动加速度为1.5g。设计保证 |
| Operation Temp. | -20~+55℃ Design assurance |
| Storage Temp. | -40~+75℃ Design assurance |
| 1 | Clean the surface of the product, do not soak the product in cleaning solution for cleaning. |
| 2 | If the temperature is higher than 125℃, consult with us before ordering. |
| 3 | / |
