FrequencyDC~18GHz, TNC-M / TNC-F, Passivation of stainless steel
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
Low VSWR, high cost-effectiveness.
| Parameters | Min | Typical | Max | Units |
|---|---|---|---|---|
| Frequency | DC | ~ | 18 | GHz |
| IL | 0.2 | dB | ||
| VSWR | 1.25 |
| Impedance | 50Ω |
| Connector | TNC-M / TNC-F |
| Product shell material | Passivation of stainless steel |
| Inner conductor | beryllium bronze gold plating |
| Spanning | PTFE+PEEK |
| Operation Temp. | -45~+85℃ Design assurance |
