Center Frequency1105MHz, Passband960~1250MHz, DC-860MHz≥65dBc, 1.35-2.0GHz≥65dBc, N
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
| Parameters | Frequency | / | Min | Typical | Max | Units |
|---|---|---|---|---|---|---|
| Center Frequency | / | / | 1105 | MHz | ||
| Passband | / | / | 960 | ~ | 1250 | MHz |
| Passband IL | / | / | 0.8 | dB | ||
| 1dB BW | / | / | 290 | MHz | ||
| Rejection | DC-860 | MHz≥ | 65 | dBc | ||
| Rejection | 1.35-2.0 | GHz≥ | 65 | dBc | ||
| Passband VSWR | / | / | 1.50 |
| Connector | N -F or K可拆0.8mm针 |
| Impedance | 50Ω |
| Surface | Conductive oxidation |
| Power Capacity | 10W Design assurance |
| Peak power | 400W Design assurance |
| Product shell material | 铝3A21，内部结构件选用铝合金5A06 |
| Operation Temp. | -55~+85℃ Design assurance |
| Storage Temp. | -55~+85℃ Design assurance |
| Weight | |
| Other | 密封要求:：激光封焊 |
| 1 | Clean the surface of the product, do not soak the product in cleaning solution for cleaning. |
| 2 | If the temperature is higher than 125℃, consult with us before ordering. |
| 3 | / |
