FrequencyDC~40GHz, SSMA-K, SSMA-K
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
High reliability and cost performance.
| Parameters | Min | Typical | Max | Units |
|---|---|---|---|---|
| Frequency | DC | ~ | 40 | GHz |
| IL | 0.2 | dB | ||
| VSWR | 1.12 | dB |
| Connector 1 | SSMA-K |
| Connector 2 | SSMA-K |
| Work Temp. | -55~+125℃ Design assurance |
| shell | Stainless steel SUS303F |
| Inner conductor | Beryllium Copper Gold Plated |
| Spanning | PEI1000 |
It is used for the connection between equipment to meet the application of test level. Please use special torque wrench to tighten it.
