| Parameters | Min | Typical | Max | Units |
|---|---|---|---|---|
| Frequency | 4430 | ~ | 4530 | MHz |
| Gain | 13 | dB | ||
| Gain flatness | ±1 | dB | ||
| VSWR | 2 | |||
| P-1dB | 30 | dBm | ||
| Psat | 33 | dBm | ||
| Max input power | 20 | dBm | ||
| Spur reduction | 40 | dBc | ||
| Harmonic Rejection | 30 | dBc |
| Connector | N -K |
| Impedance | 50Ω |
| Working voltage | +16-20V |
| Working current | ≤1A |
| Operation Temp. | -45~+75℃ Design assurance |
| Storage Temp. | -55~+85℃ Design assurance |
| Quality Grade | Industrial grade |
存储在湿度小于25%的环境，注意防尘防静电；
请注意产品的功耗，设计时考虑放大器散热问题；产品整体温度大于125℃的情况下，请在订货前与我们协商；清洗产品表面，请勿将产品浸泡清洗液中清洗。
