| Parameters | Min | Typical | Max | Units |
|---|---|---|---|---|
| Frequency | 100 | ~ | 400 | MHz |
| IL | 1 | dB | ||
| Port isolation | 70 | dB | ||
| Switch time | 1 | uS | ||
| Power Capacity | 30 | W | ||
| Working voltage | +12 | V | ||
| Working current | 150 | mA | ||
| VSWR | 1.60 |
| Parameters | Min | Typical | Max | Units |
|---|---|---|---|---|
| Frequency | 100 | ~ | 400 | MHz |
| IL | 0.65 | dB@XS1-XS2 | ||
| IL | 0.65 | dB@XS3-XS4 | ||
| IL | 0.35 | dB@XS1-XS5，XS2-XS6。XS3-XS7，XS4-XS8 | ||
| Port isolation | 95 | dB@XS1-XS2 | ||
| Port isolation | 95 | dB@XS3-XS4 | ||
| Port isolation | 60 | dB@XS1-XS5，XS2-XS6。XS3-XS7，XS4-XS8 | ||
| Switch time | SW1-WS4= | 10 | uS | |
| Power Capacity | SW1-SW4: | 200 | W | |
| Working voltage | +12 | V | ||
| Working current | 500 | mA | ||
| VSWR | 1.60 |
| Impedance | 50Ω |
| Operation Temp. | -40~+70℃ Design assurance |
| Storage Temp. | -55~+85℃ Design assurance |
| RF Port | SMP |
| 1 | Clean the surface of the product, do not soak the product in cleaning solution for cleaning. |
| 2 | If the temperature is higher than 125℃, consult with us before ordering. |
