Low power, small size and high reliability.
| Parameters | Min | Typical | Max | Units |
|---|---|---|---|---|
| Frequency | 1500 | ~ | 1600 | MHz |
| Gain | 30 | dB | ||
| Gain flatness | ±1 | dB | ||
| Noise figure | 1.0 | dB | ||
| VSWR | 1.5 |
| Connector | N -K |
| Surface | Nickel plating |
| Working voltage | +12V |
| Working current | 300mA |
| Operation Temp. | -35~+65℃ Design assurance |
Store in an environment with a humidity of less than 25% and pay attention to dust and static electricity prevention.
