110~500MHz, Gain30dB, Noise figure3dB, P-1dB10dBm, N, Gain manually adjustable
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
Gain /uploads/kmw-media/dlna8-110-500-1110/manual/DLNA8-110-500-1110@2025-05-03-21-31-21.pdfly adjustable, powered by coaxial port.
| Parameters | Min | Typical | Max | Units |
|---|---|---|---|---|
| Frequency | 110 | ~ | 500 | MHz |
| Gain | 30 | dB | ||
| Gain flatness | 3 | dB | ||
| Noise figure | 3 | dB | ||
| VSWR | 1.5 | |||
| spur reduction | 60 | dBc | ||
| P-1dB | 10 | dBm |
| Connector | N -K |
| Connector material | Stainless steel |
| Impedance | 50Ω |
| Working voltage | +24V |
| Working current | 300mA |
| Operation Temp. | -40~+70℃ Design assurance |
| Gain /uploads/kmw-media/dlna8-110-500-1110/manual/DLNA8-110-500-1110@2025-05-03-21-31-21.pdfly adjustable | 1dB step, /uploads/kmw-media/dlna8-110-500-1110/manual/DLNA8-110-500-1110@2025-05-03-21-31-21.pdf dial switch adjustable range: ≥ 20dB |
| Power input port | Coaxial SMA-F, DC power supply time ≥ 6 hours. |
Store in an environment with a humidity of less than 25% and pay attention to dust and static electricity prevention.
If the amplifier is connected to the antenna, electrostatic protection or isolation measures should be taken.
