10~3000MHz, Gain35dB, Noise figure2.8dB, P-1dB10dBm, N
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
| Parameters | Min | Typical | Max | Units |
|---|---|---|---|---|
| Frequency | 10 | ~ | 3000 | MHz |
| Gain | 35 | dB | ||
| Gain flatness | ±2.5 | dB | ||
| Noise figure | 2.8 | dB | ||
| VSWR | 2.7 | |||
| P-1dB | 10 | dBm | ||
| Max input power | 10 | dBm |
| Connector | N -F |
| Connector material | Stainless steel |
| Impedance | 50Ω |
| Working voltage | +12V |
| Working current | 300mA |
| Operation Temp. | -40~+70℃ Design assurance |
| Other | Powered by a 220V power adapter with an interface of DC 5.5mm (outer diameter) * 2.1mm (inner aperture) |
存储在湿度小于25%的环境，注意防尘防静电;
Please pay attention to the power consumption of the product and consider the issue of amplifier heat dissipation during design;
If the amplifier is directly connected to the antenna, electrostatic protection or limiter protection should be applied.
Working or storage temperature less than 125 ℃;
