1~6GHz, Gain45dB, Noise figure1.5dB, P-1dB15dBm, SMA
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
| Parameters | Min | Typical | Max | Units |
|---|---|---|---|---|
| Frequency | 1 | ~ | 6 | GHz |
| Gain | 45 | dB | ||
| Gain flatness | 4 | dB | ||
| Noise figure | 1.5 | 3 | dB | |
| VSWR | 2.5 | |||
| P-1dB | 15 | dBm |
| Connector | SMA-K |
| Impedance | 50Ω |
| Working current | 300mA |
| Operation Temp. | -20~+℃设计保证 |
| Other | Supports 220V AC and DC power supply |
| 1 | Power supply method 1 | 230V power input, standard AC interface |
|---|---|---|
| 2 | Power supply method 2 | DC power supply, interface DC 5.5mm (outer diameter) * 2.5mm (inner aperture) 220V power adapter( 12V@2A )Power supply |
| 3 | Instructions for using the power switch | The switch is equipped with a power on indicator, and the light will turn on when powered on. Either 220V or DC power supply can be used after being turned on, and cannot be used when powered on at the same time |
| 1 | 配件 | 英规电源线1条 |
|---|
Store in an environment with a humidity of less than 25% and pay attention to dust and static electricity prevention.
