0.1~8GHz, Gain32dB, Noise figure3dB, P-1dB10dBm, SMA
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
| Parameters | Min | Typical | Max | Units |
|---|---|---|---|---|
| Frequency | 0.1 | ~ | 8 | GHz |
| Gain | 32 | dB | ||
| Gain flatness | ±2 | dB | ||
| Noise figure | 3 | dB | ||
| VSWR | 2.2 | |||
| P-1dB | 10 | dBm | ||
| Max input power | 10 | dBm |
| Connector | SMA-K |
| Connector material | Stainless steel |
| Impedance | 50Ω |
| Working voltage | +220V |
| Operation Temp. | -20~+60℃ Design assurance |
| Quality Grade | Industrial grade |
| Other | 014+2071 |
| 1 | Power supply method 1 | 110-220V power input, standard AC interface, 12-15V/5W output. |
|---|---|---|
| 2 | Power supply method 2 | DC power supply, powered by a 220V power adapter with interface DC5.5mm (outer diameter) * 2.5mm (inner diameter). |
| 3 | DC output | The DC power supply voltage is determined by the input voltage of the internal module. |
| 4 | Instructions for using the power switch | 220V and DC power supply cannot be used simultaneously. |
| 5 | Shell Material | Shell aluminum material |
| 6 | Surface color | Anodizing treatment (blue) |
| 1 | Standard configuration | 220V AC power cord |
|---|---|---|
| 2 | Optional | Equipped with a power adapter |
| 3 | Other | / |
Store in an environment with a humidity of less than 25% and pay attention to dust and static electricity prevention.
If the amplifier is directly connected to the antenna, electrostatic protection or limiter protection should be applied.
