0.009~2000MHz, Gain30dB, Noise figure2.5dB@1Ghz, P-1dB10dBm, N, N
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
| Parameters | Min | Typical | Max | Units |
|---|---|---|---|---|
| Frequency | 0.009 | ~ | 2000 | MHz |
| Gain | 30 | dB | ||
| Gain flatness | ±3 | dB | ||
| Noise figure | 2.5 | dB@1Ghz | ||
| VSWR | 2 | |||
| P-1dB | 10 | dBm | ||
| Clipping level | 16 | dBm |
| Input port | N -M or J |
|---|---|
| Output port | N -F or K |
| Connector material | Stainless steel |
| Power Capacity | 10W |
| Impedance | 50Ω |
| Working voltage | +12V |
| Working current | 300mA |
| Operation Temp. | -40~+60℃ Design assurance |
| ESD静电防护 | 具备 |
| 散热齿 | 具备 |
| Other | 噪声系数=输入信号信噪比/输出信号信噪比 |
Store in an environment with humidity less than 25%, pay attention to dust and static electricity prevention;
Please pay attention to the power consumption of the product and consider the issue of amplifier heat dissipation during design;
If the amplifier is directly connected to the antenna, electrostatic protection or limiter protection should be applied.
Working or storage temperature less than 125 ℃;
Clean the surface of the product, do not soak the product in cleaning solution for cleaning.
