Frequency2~4GHz, Clipping level15dBm, 46dBm, 脉宽 3ms, 35%占空比, SMA
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
| Parameters | Min | Typical | Max | Units |
|---|---|---|---|---|
| Frequency | 2 | ~ | 4 | GHz |
| Clipping level | 15 | dBm | ||
| IL | 1 | dB | ||
| VSWR | 1.5 |
| Power | 46dBm pulse width 3ms, 35% duty cycle. Design assurance |
| Impedance | 50Ω |
| Connector | SMA-K |
| Work Temp. | -45~+75℃ Design assurance |
| Storage Temp. | -55~+85℃ Design assurance |
| Other | 对5KV的HPM大于20dB的衰减 |
1, Pay attention to the direction of input and output, reverse connection may cause the product to burn out.
