20~26GHz, Stepped frequency10MHz, Output power40dBm, 2.92
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
| Parameters | Min | Typical | Max | Units |
|---|---|---|---|---|
| Frequency | 20 | ~ | 26 | GHz |
| Stepped frequency | 10 | MHz | ||
| Stray within the band | 30 | dBc | ||
| Output power | 40 | dBm |
| Definition of DB9 | |
| 1 | 电源（+24V） |
| 2 | 电源（+24V） |
| 3 | 电源（+24V） |
| 4 | GND |
| 5 | GND |
| 6 | GND |
| 7 | TXA(RS-232) |
| 8 | RXA(RS-232) |
| 9 | EN低电平使能关，高电平使能开 |
| Connector | 2.92-K |
| Connector material | Stainless steel |
| Impedance | 50Ω |
| Surface | Nickel plating |
| Working voltage | +24V |
| Working current | 5A |
| Operation Temp. | -40~+70℃ Design assurance |
| Quality Grade | Industrial grade |
| Other | 波特率9600 |
1. Store in an environment with humidity less than 25%, pay attention to dust and static electricity prevention;
If the overall temperature of the product is greater than 125 ℃, please consult with us before placing an order;
3. Clean the surface of the product and do not soak it in cleaning solution for cleaning;
