15GHz, spur reduction70dBc, harmonic70dBc, SMA
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
| Parameters | Min | Typical | Max | Units |
|---|---|---|---|---|
| Frequency | 15 | GHz | ||
| Output power | 20 | dBm | ||
| spur reduction | 70 | dBc | ||
| harmonic | 70 | dBc |
| Connector | SMA-K detachable, Pin 0.38mm |
| Connector material | Stainless steel |
| Impedance | 50Ω |
| Surface | Conductive oxidation |
| Working voltage | +12V |
| Working current | 400mA |
| Operation Temp. | -40~+70℃ Design assurance |
| Quality Grade | Industrial grade |
| Other | Set Span to 10KHz, with a frequency accuracy offset of 15KHz and a frequency bandwidth of 0.3KHz |
1. Store in an environment with humidity less than 25%, pay attention to dust and static electricity prevention;
If the overall temperature of the product is greater than 125 ℃, please consult with us before placing an order;
3. Clean the surface of the product and do not soak it in cleaning solution for cleaning;
