Frequency15~18GHz, SMA
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
Broadband, small volume.
| Parameters | Min | Typical | Max | Units | Units |
|---|---|---|---|---|---|
| Frequency | 15 | ~ | 18 | GHz | |
| Dynamic range | -5 | ~ | +10 | dBm | |
| 电压灵敏度 | 10 | mV | @0dBm | ||
| VSWR | 2 | ||||
| 脉冲输入延迟 | 50 | ns | |||
| 脉冲输入上升时间 | 50 | ns | @0dBm | ||
| 脉冲输出下降时间 | 50 | ns | @0dBm |
| Impedance | 50Ω |
| Connector | SMA-JK detachable, Pin 0.38mm |
| Connector material | Stainless steel |
| Surface | Gold-plating |
| Operation Temp. | -40~+85℃ Design assurance |
| Other | 脉冲使用 |
1、注意输入输出方向。
