Low loss.
| Parameters | Min | Typical | Max | Units |
|---|---|---|---|---|
| Frequency | 32.9 | ~ | 50 | GHz |
| IL | 0.4 | dB | ||
| VSWR | 1.35 |
| Power Capacity | 10W |
| Waveguide model | Rect waveguider |
| Connector 1 | BJ400 |
| Connector 2 | 1.85-K |
| Flange model | FUGP400 |
| Surface | Gold-plating |
| Product shell material | Copper |
| Operation Temp. | -45~+85℃ Design assurance |
