工作频率 J1DC-1.7GHz, 工作频率 J22.0-18.0GHz
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
High performance, ultra bandwidth
Low loss, high isolation
Small size, excellent performance
Customizable according to requirements
| Items | Parameters | Units |
|---|---|---|
| 工作频率 J1 | DC-1.7 | GHz |
| 工作频率 J2 | 2.0-18.0 | GHz |
| IL | <2.0 | dB |
| Ripple | <2.0 | dB |
| VSWR | <2.0:1 | |
| Reverse isolation | >30 | dB |
| 带外抑制 J1 | >50@2.0-2.1GHz | dB |
| 带外抑制 J1 | >60@2.1-18.0GHz | dB |
| 带外抑制 J2 | >60@DC-1.6GHz | dB |
| 带外抑制 J2 | >40@1.6-1.7GHz | dB |
| 带外抑制 J2 | >40@19.0-20.7GHz | dB |
| 带外抑制 J2 | >60@20.7-25.0GHz | dB |
| Port form | SMA-K |
| surface treatment | Black paint |
| power | 5W CW |
| Operation Temp. | -40~+70℃ |
| Storage Temp. | -55~+85℃ |
1:产品安装在设备或系统中，避免因振动或冲击导致性能下降或损坏
2: Good grounding of products and systems to reduce electromagnetic interference and signal reflection;
3:输入和输出端口的阻抗匹配，通常为50欧姆。使用合适的连接器和电缆，避免阻抗不匹配导致的信号反射
4:在高功率应用中，腔体微带频分器有良好的散热设计，避免因过热导致性能下降或损坏
