BandwidthDC-4.6GHz, Rejection34@5.6-11.0GHz, 15@11.0-13.5GHz
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
低插入损耗
良好的抑制
大功率、低温漂
实验室、测试仪器
坚固耐用的不锈钢壳体
| Items | Parameters | Units |
|---|---|---|
| Center Frequency | 2.3 | GHz |
| Bandwidth | DC-4.6 | GHz |
| Center loss | 2.0 | dB |
| Ripple | 2.0 | dB |
| VSWR | 1.7:1 | |
| Group delay ripple | 1.0 | ns |
| Rejection | 34@5.6-11.0GHz | dBc |
| Rejection | 15@11.0-13.5GHz | dBc |
| Impedance | 50ohm |
| Port connection | SMA-K，SMA-J |
| power | 5W CW |
| Operation Temp. | -45~+85℃ |
| Storage Temp. | -55~+85℃ |
1:在安装过程中旋转连接器螺母进行连接，不能旋转滤波器或电缆进行连接，旋转滤波器和电缆连接容易导致内导体损坏;
2:在清洗过程中滤波器不能浸泡在清洗液中，清洗剂可能进入盒体中，改变产品内部元件的固化状态和参数，造成滤波特性恶化，甚至产品失效;
