2~18GHz, Attenuation range0~30dB, step10dB, 衰减位数4Bit, Switching time80ns, 23dB, SMA
To check stock availability, search under "In-stock Products" on the Dianzibuy store.
Any change to the content of this page is subject to change without notice. Please confirm the specifications before ordering.
Products must not be used for any unlawful purpose; the customer bears any loss arising from unlawful use.
--
| Parameters | Min | Typical | Max | Units |
|---|---|---|---|---|
| Frequency | 2 | ~ | 18 | GHz |
| Attenuation range | 0 | ~ | 30 | dB |
| IL | 5 | dB | ||
| VSWR | 2 | |||
| Attenuation accuracy | ±3 | dB |
| step | 10dB |
| 衰减位数 | 4 Bit |
| Switching time | 80ns |
| Power Capacity | 23dB设计保证 |
| Impedance | 50Ω |
| Connector | SMA-F |
| Surface | Grey |
| Working voltage | ±5V |
| Working current | ±30mA |
| Operation Temp. | -40~+70℃ Design assurance |
| Storage Temp. | -55~+85℃ Design assurance |
| Quality Grade | Industrial grade |
| No. | T1 | T2 | state |
|---|---|---|---|
| 1 | 0 | 0 | Through |
| 2 | 0 | 1 | 衰减10dB |
| 3 | 1 | 0 | 衰减20dB |
| 4 | 1 | 1 | 衰减30dB |
